RTF 65A 4in1 6S Lite AT

SKU:
The RTF 65A 4in1 6S Lite AT is a compact, powerful 4-in-1 ESC engineered for 130-300mm wheelbase FPV racing drones. Boasting 65A continuous current (80A peak) per channel and compatibility with 4-6S LiPo batteries, it delivers reliable power for agile flight. With a tiny 44×44×5.86mm footprint and 15g weight, it saves valuable space on lightweight builds. It supports PWM/DShot300/600 throttle signals, bidirectional DShot, and motor direction adjustment—all configurable via BLHeliSuite software. The self-developed 32-bit ESC program and 48kHz drive frequency ensure smooth, responsive motor control. Pre-soldered pads (no pre-attached wires/plugs) offer flexible customization for racing drone enthusiasts.
0.0 (0 Reviews)
0 Sold
$0.00 $0.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • RTF 65A 4in1 6S Lite AT
  • RTF 65A 4in1 6S Lite AT
  • RTF 65A 4in1 6S Lite AT
  • RTF 65A 4in1 6S Lite AT
  • RTF 65A 4in1 6S Lite AT
  • RTF 65A 4in1 6S Lite AT
1/1
  • RTF 65A 4in1 6S Lite AT
  • RTF 65A 4in1 6S Lite AT
  • RTF 65A 4in1 6S Lite AT
  • Description
RTF 65A 4in1 6S Lite AT
Model RTF 65A 4in1 6S Lite AT
Continuous/Peak Current 65A×4/80A×4
Battery Cell Count 4-6S LiPo
Power Cable Red-12AWG-130MM×1; Black-12AWG-130MM×1
Motor Output Wire None, pre-soldered pad
Power Plug No plug
ESC Slot 8Pin-SH1.0
Dimensions 44×44×5.86mm
Weight 15g
Firmware Self-developed 32-bit ESC program
Programming & Parameter Adjustment Supports BLHeliSuite software adjustment
Throttle Signal Support PWM, DShot300/600
Bidirectional DShot Supported
Motor Direction Setting Supported
Drive Frequency Setting 48kHz
Typical Application 130-300mm wheelbase FPV racing drone
